7401445/4261582GB
Baer Brakes 15" Extreme+ Front Brake Kit, Grabber Blue, SDZ, Std. Studs
- Brand Baer Brakes
- Model 4261582GB
- Availability Available To Order
The Extreme+ system comes with the 1-piece Monoblock 6-piston, 6S caliper mounted to a 15", 2 piece slot, drill, zinc plated rotor. The 6S caliper is fully machined in Phoenix, AZ from a US sourced 2618 Aluminum forging, includes stainless steel pistons and abutments, D.O.T. compliant dust and weather seals and uses the popular D1247 pad type. Rotors are pre-assembled with NAS high grade stainless hardware. Billet aluminum hubs come assembled with premium bearings packed with Redline synthetic grease and billet dust caps. All mounting brackets and hardware are also included. The 15” Extreme+ fits most 19” or larger wheels.
Fits Wilwood Mustang II Pro Spindles
References
| Brand | Baer Brakes |
| Category | Newest |
| Product Code | 7401445 |
| SKU: | 4261582GB |
Specifications
| Brand | Baer Brakes |
| Emission Code | 6 |
| Product Type | 15 Inch Extreme+ Front Brake Kit |
| Product Line | 15 Inch Extreme+ |
| Title | Extreme+ Brake System Front |
| Caliper Color | Grabber Blue |
| Axle | Front |
| System Notes | Designed to be used with Wilwood Mustang II Pro Spindles (Stock & Drop Height) |
| Export Description | Brake Components |
| Min Wheel Dia (verify using template) | 19 (in) |
| Prop 65 - Long Label | WARNING: This product can expose you to chemicals including Toluene Diisocyanate, and Nickel which are known to the State of California to cause cancer. For more information, visit www.P65Warnings.ca.gov |
| Surface Type | Slotted, Drilled & Zinc Plated |
| Template | N147U |
| Caliper | 6S |
| Disc Brake Caliper (Front) Type | Fixed |
| Disc Brake Pad FMSI Number | D1247 |
| Disc Brake Rotor (Front) Construction | Vented |
| Hose Material | Hoses Not Included |
| Lug Count | 5 Lug |
| Prop 65 (C, R or CR) | CR |
| Prop 65 Yes/No | Yes |
| Rotor Thickness | 1.250 (in) |
| Wheel Lug/Bolt Pattern | 5x4.50/5x4.75 |
| Wheel Stud Size | 1/2-20" x 2.25" |
| Grade Type | Performance |
| Rotor Type | 2-Piece |
| Disc Brake Caliper (Front) Piston Quantity | 6 |
| Disc Brake Rotor (Front) Outside Diameter | 15.000 (in) |
| Spindle Type | Wilwood Mustang II Pro |
| Spindles Included | No |
Specifications
| Brand | Baer Brakes |
| Emission Code | 6 |
| Product Type | 15 Inch Extreme+ Front Brake Kit |
| Product Line | 15 Inch Extreme+ |
| Title | Extreme+ Brake System Front |
| Caliper Color | Grabber Blue |
| Axle | Front |
| System Notes | Designed to be used with Wilwood Mustang II Pro Spindles (Stock & Drop Height) |
| Export Description | Brake Components |
| Min Wheel Dia (verify using template) | 19 (in) |
| Prop 65 - Long Label | WARNING: This product can expose you to chemicals including Toluene Diisocyanate, and Nickel which are known to the State of California to cause cancer. For more information, visit www.P65Warnings.ca.gov |
| Surface Type | Slotted, Drilled & Zinc Plated |
| Template | N147U |
| Caliper | 6S |
| Disc Brake Caliper (Front) Type | Fixed |
| Disc Brake Pad FMSI Number | D1247 |
| Disc Brake Rotor (Front) Construction | Vented |
| Hose Material | Hoses Not Included |
| Lug Count | 5 Lug |
| Prop 65 (C, R or CR) | CR |
| Prop 65 Yes/No | Yes |
| Rotor Thickness | 1.250 (in) |
| Wheel Lug/Bolt Pattern | 5x4.50/5x4.75 |
| Wheel Stud Size | 1/2-20" x 2.25" |
| Grade Type | Performance |
| Rotor Type | 2-Piece |
| Disc Brake Caliper (Front) Piston Quantity | 6 |
| Disc Brake Rotor (Front) Outside Diameter | 15.000 (in) |
| Spindle Type | Wilwood Mustang II Pro |
| Spindles Included | No |
