A magnetic pick-up triggers your MSD Ignition Control accurately at any rpm. Above this pick-up the mechanical advance assembly is positioned so it can be adjusted without disassembling the distributor. In addition, the specially ground advance cam is tig-welded to the 9/16" hardened shaft and the weight pins are staked and TIG-welded to the advance plate.

Features

CNC machined billet aluminum housing and billet aluminum base

Will not accept a vacuum advance or MSD Cap-A-Dapt

Supplied with an HEI style distributor cap and rotor

Must be used with an MSD Ignition Control

Mechanical advance assembly can be locked out for crank trigger systems

Nylon pads ensure smooth operation of the advance weights

Advance weight pins are staked and tig welded to the plate

Advance plate and weights are fine blanked from chrome moly steel and QPQ coated for friction reduction

Polished steel shaft is QPQ coated and guided by a sealed ball bearing

Maintenance-free magnetic pickup and precision reluctor create stable trigger signals throughout the rpm range

Easy-to-adjust mechanical advance with supplied springs and stop bushings

No CARB Exemption Order Number
