Specifications:

• Gas tank has a right side petcock location, and a fuel capacity of 2.5 gallons
• The tank is universal with front and rear mounting tabs
• It uses a 3/8" National Pipe Thread style petcock, pre-1975
• Check the tank for flaws and fit before painting. Do not grind or sand the seams or joints. Clean the inside of the tank
• It is suggested to pressure test and use a tank sealer. We suggest using Kreem gas tank combo kit to clean, condition, and seal to help stop leaks and prevent corrosion
• Check the petcock opening, making sure the petcock can be easily installed. The petcock fitting should be masked or plugged during painting for easy installation of the petcock
• Tank accepts Bayonet vented style gas caps
• The tank has undrilled tab front and rear for surface mounting on top frame tube

Dimensions:

• Top Length: 19"
• Bottom Length: 13"
• Rear Width: 4"
• Front Width: 8"
• Rear Height: 2-1/2"
• Front Height: 6-1/2"
• Front Tunnel Height: 3"
• Rear Tunnel Height: 1-1/2"
• Tunnel Length: 15"
• Tunnel Width: 2-1/4"

Fits: Custom Applications
